1
|
GACS2017 |
 |
SWINGARM WELDED ASSY- 2017 KING |
$194.60 |
|
|
2
|
HCBH1203 |
 |
M12 X 188.5 PIVOT BOLT |
$32.14 |
|
|
3
|
HCNL1201 |
 |
M12-1.25 LOCKNUT FINE THREAD |
$3.20 |
|
|
4
|
GCMU0001 |
 |
SWINGARM BUSHING 1-INDIVIDUAL |
$10.55 |
|
|
5
|
PAKG0001 |
 |
CHAIN BLOCK ASSY |
$30.02 |
|
|
6
|
HCNL0601 |
 |
M6 LOCKNUT |
$1.09 |
|
|
7
|
HCBF0620 |
 |
M6 X 20 FLANGE HD HEX 8MM ZINC 8.8 |
$1.09 |
|
|
8
|
GCCS0001 |
 |
SPACER - SWNGARM PIVOT TUBE KG 10-16 / ALL 50cc 2017- LATER |
$13.67 |
|
|
9
|
FAMU0005 |
 |
WHEEL PULL ASSEMBLY |
$32.25 |
|
|
10
|
FCMU0203 |
 |
WHEEL PULL |
$24.35 |
|
|
11
|
FCMU0202 |
 |
ENDCAP - WHEEL PULL - KING & CM |
$8.77 |
|
|
12
|
HCBH0810 |
 |
M8 X 65 HH FULL THREADS ZINC |
$1.54 |
|
|
13
|
HCWL0801 |
 |
8MM LOCK WASHER STANDARD |
$0.53 |
|
|
14
|
WCMU0016 |
 |
M12 X 195MM AXLE / PIVOT BOLT |
$32.14 |
|
|
14A
|
HCWF1202 |
 |
12MM FLAT WASHER |
$0.53 |
|
|
15
|
GCMU0040 |
|
SWINGARM CHAIN GUARD - CX50 - WITH MOHAWK |
$16.56 |
|
|
16
|
HCFH0516 |
 |
M5 X 16 FLAT HEAD |
$1.09 |
|
|
18
|
GCMU0038 |
 |
WASHER - RETAINING - SWINGARM GUARD |
$4.32 |
|
|
19
|
PCKG0004 |
 |
CHAIN GUIDE - SLIDER BOTTOM |
$10.99 |
|
|
20
|
HCCC0000 |
 |
CABLE CLAMP-3/8 INCH |
$1.09 |
|
|
21
|
HCPP0832 |
 |
#8X1/2 SELF TAPPING SCREW |
$1.09 |
|
|
22
|
HCCC0005 |
 |
GUIDE - REAR BRAKE HOSE |
$5.88 |
|
|
24
|
HCPP0834 |
 |
#8X3/4 SELF TAPPING SCREW |
$1.09 |
|
|
25
|
PCMU0002BLK |
|
CHAIN GUIDE OUTER - BILLET - BLACK |
$27.68 |
|
